Item

Part No.

Description

1

070711

Clamp band assembly

1

357150

Clamp, Cam & RampTM

1

357199

Clamp, Cam & Ramp

1A

071136Z

Knob

2

070795

Cover, clear

2

357151

Cover, clear, WFE pump

2

357156

Cover, chemical resistant Cam & Ramp

3

071422

O-ring

3

350013

O-ring

3

0-218-0

O-ring

4

070387

Basket

4

B-199

Basket

5

070430

Bolt, 3/8, 16 x 1-1/4 hex hd. SS, 4 req.

6

072184

Washer, 3/8 x 13/16 o.d. SS, 6 req.

7

070431

Bolt,3/8, 16 x 1-3/4 hex hd. SS, 2 req.

8

071403

Nut, 3/8, 16 hex hd., 2 req.

9

071445

O-ring parker No.2-265, WFE pump

9

357100

Black Gasket for Seal Plate

9

357102

Almond Gasket for Seal Plate

10

357149

Volute & Sealplate, Almond Replacement Kit

10

350015

Volute, almond

10

357157

Volute, black

11

355227

O-ring parker No.2-238, WFE pump

11

0-359-0

12

071660

Set screw, 4-40 x 1-1/8 WFE, 2 req.

13

072928

Diffuser assembly, WFE-12, 3 HP; WFK-12, 3HP models

13

072927

Diffuser assembly, WFE-2–8, 1/2 HP – 2-1/2 HP

14

071652

Set screw, 1/4, 20 x 1 lh. phillips

15

075713

Rubber washer, WFE pump

16

071734S

Seal PA-7 w/ ceramic seat, PS1000

16

PS-1000

     17

070429

Bolt, 3/8, 16 x 7/8 SS hex hd., 4 req.

18

350202

Seal Plate Kit, Almond with Gasket

18

350101

Seal Plate Kit WFE Black

19

070927

Foot, WFE-4 pump, almond

19

357159

Foot, black ⁹

20

070929

Foot insert, WFE pump, almond

20

357160

Foot insert, WFE pump, black ⁹

21

071657

Screw, 1/4, 20 x 1 in. hh. SS, 2 req.

22

071406

Nut, 1/4, 20 hex. hd. SS, 2 req.

23

072183

Washer, flat 1/4 x 5/8, 2 req.

24

071131

Knob plug drain, 2 req. almond

24

357161

Knob plug drain, 2 req., black ⁹

25

192115

O-Ring drain plug, 2 req.

26

357149

(Includes items 1-4, 9, 10, 16, 18, 24, 25.)

MOTORS

27

355008S

3sp, almond /4 HP, 60 Hz, WFE-2, 3 & 24, 2 1 3

27

355010S

1 HP, 60 Hz, WFE-4 & 26, 1 sp, almond ³

27

355012S

1-1/2 HP, 60 Hz, WFE-6 & 28, 1 sp, almond ³

27

355014S

2 HP, 60 Hz, WFE-8 & 30, 1 sp, almond ³

27

355016S

3 HP, 60 Hz, WFE-12, 1 sp,

almond

27

350088S

3/4 HP, 2 sp, WFDS-3

27

356630S

1 HP, 2 sp., WFDS-4 & 26

27

071320S

1-1/2 HP, 2 sp., WFDS-6 &28

27

071321S

2 HP, 2 sp, WFDS-8 & 30

27

355018S

1/2 HP, WF-2, 23, 1 sp, almond

27

355020S

3/4 HP, WF-3, 24, 1 sp, almond

27

355022S

1 HP, WF-4, 26, 1 sp, almond

27

355024S

1-1/2 HP, WF-6, 28

27

355026S

2 HP, WF-8, 30

27

355033S

3 HP, 1 sp, WF-12, 1 sp, almond

27

354805S

1 HP, 3 ph, 1 sp, sq. flg. almond, WFK-4

27

354807S

1.5 HP, 3 ph, 1 sp, sq. flg. almond, WFK-6

27

354809S

2 HP, 3 ph, 1 sp, sq. flg. almond, WFK-8

27

354811S

3 HP, 3 ph, 1 sp, sq. flg. almond, WFK-12

27

354806S

WFK-4 motor, 3 ph, 1 sp, black

27

354808S

WFK-6 motor, 3 ph, 1 sp, black

27

354810S

WFK-8 motor, 3 ph, 1 sp, black

27

354812S

WFK-12 motor, 3 ph, 1 sp, black

IMPELLERS

28

073126

Impeller (WF-2, WF-23, WFE-2, WFK-2,)

28

073127

Impeller (WFE-3, WFE-24, WF-3,

WF-24, WFK-3, WFDS-3, WFDS- 24)

28

073128

Impeller (WFE-4, WFE-26, WF-4,

WF-26, WFK-4, WFDS-4, WFDS-26)

28

073129

Impeller (WF-6, WF-28, WFE-6, WFE-28, WFK-6, WFDS-6, WFDS-28)

28

073130

Impeller (WF-8, WF-30, WFE-8, WFE-30, WFK-8, WFDS-8, WFDS-30)

28

073131

Impeller (WFE-12, WF-12, WFK-12)
