Finish:
Chip and fade resistant polyester powder
coating.
Housing:
Die cast aluminum 1/2" NPS tapped holes
top, both sides and back for conduit or
photocontrol. Hinged refractor frame,
Continuous silicone rubber gasket.
Reflector:
Specular anodized aluminum, removable for
installation. Symmetrical light pattern
maximizes distance between fixtures.
Refractor:
Prismatic optics designed to minimize glare
and throw light down and out. Heat resistant
borosilicate glass.
UL Listing:
Suitable for wet locations. HID fixtures can
be wired with 90° C supply wiring if supply
wires are routed 3" away from the ballast.
Patents:
RAB sensor and fixture designs are
protected under U.S. and International
Intellectual Property laws.
Photocell:
Button Photocell installed and wired for
120V Quad Tap:
Fixture works with 120, 208, 240, and 277
volts
Color: Bronze
Weight: 28.9
